302 stainless steel pipe has excellent plasticity and toughness and works for various processing techniques, including cold working, so it can be manufactured in different shapes. And 302 stainless steel has good corrosion resistance, especially in oxidizing acids, atmosphere, steam and water. However, 302 stainless steel does not suit intergranular corrosion environments, so it is not recommended for environments with risks of intergranular corrosion. The chemical composition and performance characteristics of 302 stainless steel make it an ideal material for a variety of applications, including the manufacture of structural parts, weldments, non-magnetic components and cryogenic device components. Globally, there is a number of international corresponding brands to adapt to the standards and needs of different regions.
Product Parameters
| Product Name | 302 Stainless Steel Pipe | |
| Type | Steel Pipe | |
| Outer diameter | Round Tube | 4mm-200mm |
| Square Tube | 10*10mm-100*100mm | |
| Rectangular Tube | 10*20mm-50*100mm | |
| Wall Thickness | 0.6mm-6.0mm | |
| Length | 1-6 meters, Length can be customized | |
| Standard | ASTM, AISI, JIS, GB, DIN, EN, etc. | |
| Surface | Black, Bright Polished, Rough Turning, Matt Surface Treatment, No. 4. BA, etc. | |
| Scope of Application | Common applications for stainless steel pipes include food processing,Textile operations, Breweries, Water treatment plants, Oil and gas processing,Fertilizers and pesticides, Chemical applications, Construction, Pharmaceuticals, Auto parts, etc. | |
| Certificate | ISO, SGS, BV, etc. | |
| Production Technology | Hot Rolling, Cold Rolling | |
| Edge Processing | Edging, Trimming | |
Chemical Composition
| C | Si | Mn | Cr | Ni | S | P |
| ≤ 0.15 | ≤1.0 | ≤ 2.0 | 17.0~19.0 | 8.0~10.0 | ≤ 0.03 | ≤ 0.035 |
Mechanical Properties
| Tensile Strength Kb (MPa) | Yield Strength σ0.2 (MPa) | Elongation D5 (%) | Hardness |
| ≥ 520 | ≥ 205 | ≥ 40 | ≤ 187HB ;≤ 90HRB;≤ 200HV |
Physical Performance
| Density(g/cm³) | Modulus of Elasticity(Gpa) | Coefficient of Thermal Expansion(10-6/°C) | Coefficient of Thermal Conductivity(W/m*K) | Resistivity(μohm.in) |
| 7.93 | 200 | 17.6 | 16.3 | 27.4 |
